Large-Scale Logistics Pallet Production Line
In the logistics sector, pallets are core tools for containerized, standardized handling, and storage of goods. The 16kg lightweight pallet plays a significant role in optimizing logistics efficiency, reducing costs, and ensuring cargo safety. With an actual load capacity of 500-1000kg, the 16kg standardized lightweight pallet is widely used in e-commerce, light industry, cold chain logistics, and other fields, aligning with the future trends of intelligent and integrated logistics.
DKM Delivers Professional Solutions
As an industry leader, DKM deeply understands market demands and has launched an efficient solution tailored for 16kg pallet production. The full production line integrates the DKM-2350TP two-platen injection molding machine, Sino Mould, ABB automated part removal robotic arms, high-power chillers, and integrated feeding systems. Through comprehensive optimizations in mold cooling, mold clamping, plasticizing, injection, and other processes, the system achieves a 69-second cycle time per 16kg pallet.
cycle time
69S
Technical Features and Advantages
lPatented center-clamping design ensures even clamping force distribution, high mold closure accuracy, and reduced flash or internal defects.
lServo-driven system saves energy and reduces noise (30% lower energy consumption vs. traditional hydraulic systems), with customizable functions like synchronized plasticizing, ejection, and detachable safety doors.
lCompatible with polypropylene (PP), polyethylene (PE), and other common plastics. Supports reinforced fibers or recycled plastics for eco-friendly pallet production.
lP20 high-hardness steel molds ensure durability in long-term high-pressure production environments.
lSingle-shot molding eliminates secondary processing, directly producing double-sided or single-sided pallets to reduce labor costs.
lSupports complex designs (e.g., nine-foot or grid-bottom structures) to enhance anti-slip properties and stacking stability.
Pallet Types and Recommended Molding Machine Tonnage
| Clamping Force Range | Pallet Type | Production Features | Target Users |
|---|---|---|---|
| 1500-2000T | Small/Medium (e.g., 9-foot) | Cost-effective, moderate complexity | SMEs |
| 2350T-2800T | Large/Complex Structures | High precision, efficiency, load capacity | Smart warehousing/logistics hubs |
| 3350T-4000T | Extra-Large (e.g., foldable) | Large molds, longer cycles | Large logistics carriers |
Future Development Trends
Smart Manufacturing
IoT-enabled interfaces for remote monitoring and predictive maintenance. AI-optimized parameters (temperature, pressure) to reduce defect rates.
Green Manufacturing
Promote recycled plastics and biodegradable pallets to reduce carbon emissions. Implement plastic foaming technology to minimize material waste and costs.
